SS-26GS/28GS/30GS
Computerized single needle quilting machine
Keywords:
Quilting machine
Product Description
- Product Description
-
Computerized single needle quilting machine
Motor:Servo motor
Auto thread trimming function
Auto hook lubrication
Stitch length:2-7mm adjustable
Power:single Phase 220V 50HZ1)Controled by servo motor, Max speed is 3000 rpm.
2)The main shaft move, floor space is smaller.
3)Needle head controled by two servo motor, low noise when moving.
4)Any pattern auto quilting,equal distance needle quilting.
5)Easy modification operation of needle distance and speed.
6)Clockwise-conuter clockwise quilting and empty forward or backward orthread-though botton is provided.
7)The needle automatically stops when any broken thread is automaticallydetected.
8)The machine stop when ay broken thread is automatically detected.
9) Quilting condition and operation indication are shown in real time.
10)lt automatically returns to original point.
11) lt has the function of pattern tracing to make the needle position quickly.
12)lt has hte function of pattern browsing.
13)lt has the function ofwork-piece and time statistics.
14)Through pattern side setting up, it can automatically enlarge or reducepatterns.
Model Quilting width(m) Machine measure ment(m)L*W*H Max size of quilt(m) Max needle drop size(m) Max speed(rpm) Quilting thickness(mm) Weight(t) SS-26GS 2.6 3.52×3.5×1.3 2.6×2.8 2.4×2.6 3000 5-50 1.5 SS-28GS 2.8 3.72×3.7×1.3 2.8×3.2 2.6×3.0 3000 5-50 1.6 SS-30GS 3 3.92×3.9×1.3 3.0x×3.2 2.8×3.2 3000 5-50 1.7 SS-26ZGS 2.6 3.65×5×1.55 2.6×2.8 2.4×2.6 3000 5-50 1.45 SS-30ZGS 3 3.95×5.4×1.55 2.8×3.0 2.6×2.8 3000 5-50 1.55
