SS-64-2GS/SS-94-3GS/SS-118-3GS/SS-128-3GS
Computerized lockstitch multi-needle quilting machine
Keywords:
Quilting machine
Product Description
- Product Description
-
Computerized lockstitch multi-needle quilting machine
1)Computer use Windows operate software,LCD screen,Adopting CNC controlprogram.
2) The moving structure of needle bar is without needle post to avoid dirtying thematerials.improve the working speed of machine,don't need to lubricatefrequent.it's easy to maintenance.Saddles and rollers driven by servo devices.
3) Fabric roller which in front of machine controled with motor, make fabric moretighter,design will be more beautiful.The main shaft adopt inverter controlequipment.
4)Self-provided large quilting designs for your choice.
5)Easy and quick editing of patterns.
6)3600 all-round pattern arbitrary quilting.
7)Function to quilt independent patterns
8)stitches length between 2mm-6mm adjustable,
9) Function of pattern compensation,an effective solution to the distortion ofpatterns when quilting thick materials.
10)Quilting, simulation shows.
11)Automatic pick-up needle, orientation brake system
12)X/Y direction used servo controned ensure the precision of quilting.
13) Infrared thread break detector sensors to guarantee the safety of the operator.
Main motor: Servo motor
Stitch length: 2-7mm
Shuttle:7#，10#
Power:3-phase 380V 50Hz
Model Quiltin width Machine dimensions(LxWxH)m Neede lines Head pich
( mm)Space between 2 needle lines(mm) Speed(rpm/min) Weight
(t)Power
(kw)SS-64-2GS 64"(1.64m) 3.86×1.5×24 2 25.4 76.2 500-700 3.5 2 SS-64-305 64"(1.64m) 3.86×1.5×2.4 3 25.4 76.2 500-700 3.5 2 55-94-208 94"(2.4m) 4.62×1.5×2.4 2 25.4 76.2 500-700 35 28 55-04-305 94"(2.4m) 4.62×1.5×2.4 3 25.4 76.2,76.2,152.4 500-700 4.5 3. 58-118-305 118"(3.1m) 5.32×1.5×2.4 3 25.4 76.2,76.2,152.4 500-700 5.5 3.9 55-128-308 120"(3.2m) 5.32×1.5×2.4 3 25.4 76.2,76.2,152.4 500-700 5.5 4.2
